    Lonking CDM932N 1.5TON 0.8m3 wheel loader with YUNNEI engine YN38GB1

    Ask Lasest Price
    Brand Name : Lonking
    Model Number : CDM932N
    Certification : ISO 9001-2008
    Delivery Time : Normally within 10 days
    • Product Details
    • Company Profile

    Lonking CDM932N 1.5TON 0.8m3 wheel loader with YUNNEI engine YN38GB1

    Lonking CDM932N 1.5TON 0.8m3 wheel loader with YUNNEI engine YN38GB1


    Lonking -Top Brand Wheel Loader Manufacturer


    200,000 Units More Working Worldwide


    Pay Loader, Chinese Pay Loader, Chinese Wheel Loader, Chinese 3T Wheel Loader, Chinese 5T Wheel Loader,
    Chinese Large Wheel Loader, Chinese Small Wheel Loader, 1T-2.3T wheel loader

    Cummins Engines and ZF Transmission & Axles
    Pilot Control System, Automatic Leveling
    Complete line of applications and accessories
    Easy maintenance & Outstanding After-sales
    Top brand quality, reliable and save 20% plus


    Supply Lonking complete series of wheel loader , include 1.2ton , 1.5ton ,2ton ,3ton ,3.5ton , 4ton ,5ton ,6.5ton ,7ton


    CONFIGURATION
    YUNNEI Engine
    Lonking Transmission
    Lonking Torque Converter
    Lonking Drive Axle
    Pilot Control Working System
    Hight Dump
    Air Conditioner
    TECHNICAL PARAMETERS
    BasicBucket capcity0.8m3
    Rated payload1500kg
    Operating weight5230kg
    Traction force52kN
    Breakout force35kN
    L*W*H5925*2100*2950mm
    EngineManufacturer/ModelYUNNEI/YN38GB1(Nation II)
    Rated power65kw/2400rpm
    Rated torque285N.m/1600-1800rmp
    Drive trainTransmission typeCountershaft powershift
    Shift TypeFixed shaft hydraulic shift spur gear
    Pressure of transmission1.1-1.5MPa
    Gear2F/2R
    Torque converterSingle-stage,single turbine ,3 element
    Torque ratio3.13
    Main reducerSpiral bevel gear single-stage reduction
    Final reducerPlanetary reduction
    Tire16/70-20
    Travel spped -forward8/20km/h
    Travel spped -reverse8/20km/h
    Brake systemService brakeAir drive ,four wheel brake (dry)
    Setting pressure0.78MPa
    Parking brakeFlexible shaft controlled caliper
    Steering systemTypeHydaulic load sensor system
    Steering pumpShared with working pump
    System pressure14MPa
    Steering angle±30°
    Hydarulic systemTypePilot Control
    Working pumpGear pump
    Flow rate120L/min.2400 rpm
    Control valve2 Spool
    System pressure16MPa
    Cycle time (sec)8.2
    Electric systemSystem voltage2.4V
    Battery (2 in series )2*90Ah
    Service refill capacityFuel tank90L
    Hydraulic tank65L
    Transmission type19L
    Front axle/ rear axle24L

    OPTIONAL
    Bucket (1.2M3 ,width 2.1m, 3 Piece cutting edges )
    Bucket (1.2m3, width 2.1m, Five detachable teeths )
    3rd spool for auxiliary function
    Hydraulic quick hitch
    Quick hitch bucket (3 piece cutting edges )
    Quick hitch log fork
    Mechanical quick hitch
    Copper slag grapple
    Log fork
    Warm air blower
